PdfTableCreate(rows As Integer, cols As Integer, width As Double, rowheight As Double) As Integer

Create a new pdf table object.

Parameters:

Name	Type	Description
rows	Integer	The number of rows which should be pre-allocated. The value should be large enough to avoid unnecessary memory reallocations. Note that this is just the size of the array that holds the rows which will be added later. Unused rows require 4 or 8 bytes memory (32 bit / 64 bit).
cols	Integer	The number of rows which should be pre-allocated.
width	Double	The width of the table in points, for example: 200.0 The widths of the columns is set to the table width divided by the number of columns (Width / NumCols). To set width of columns, see: PdfTableSetColumnWidth
rowheight	Double	Default row height in points. The specified rowheight represents the minumum height of each row. If the height of a foreground object is larger, then the row height will be adjusted. Example row height: 9.0 The default row height is used if the parameter height of PdfTableAddRow or PdfTableAddRows is set to a negative value.

Returns:

Type	Value	Description
Integer	>= 0	The identification number (handle) of a table
Integer	-1	failed to create a new table object
Integer	-2	An unknown exception occured

Available in:

WindowMain	WindowLink
YES	YES

Used in:

XojoScript Name	GUID
Create Seminar Invoice With Slip As PDF	739DA58E-17EE-41CE-BB54-E7362CFE17D4
Create Seminar Invoice As PDF	2C3F7F29-A29A-4338-ACF5-51894B709DA5

Hint: You can find references to XojoScripts which make use of this function by sending the following SQL statement to the database:

Select id,GUID, ScriptName,ScriptCode from im_scripts where ScriptCode Like '%PdfTableCreate%'

Example XojoScript:

// Create pdf file and add table with 5 rows

If PdfStart("testfile.pdf") > 0 Then

// Set top top-left as 0,0 coordinates

PdfSetPageCoordsTopDown

Dim hTbl As Integer = PdfTableCreate(1,1,200.0,9.0)

If hTbl >= 0 Then

// Set outer border

Call PdfTableSetBorderWidth(hTbl,-1, -1, 0.5, 0.5, 0.5, 0.5)

// Set inner gridlines

Call PdfTableSetGridWidth(hTbl, 0.5,0.5)

// Add 5 rows of 15.0 points row height

Call PdfTableAddRows(hTbl,5,15.0)

// Draw the table to pdf, at coordinates x=30 y=30

Call PdfTableDraw(hTbl,30.0,30.0,0.0) // 0.0 = avoid pagebreaks

End If // hTbl >= 0

// Finalize PDF

Call PdfCloseFile

// Open PDF in default viewer

Call Pdflaunch

End If // PdfStart("testfile.pdf")
